The Fiat Abarth 1000 TCR Berlina Corse is a true motorsport icon and dominated the European Touring Car Championship class in 1968 and 1969. Based on the small Fiat 600, the car was transformed by Abarth into an uncompromising racing machine: wide fenders, enlarged front radiator, horizontal hood opening, and a powerful 982cc four-cylinder engine producing over 110 hp.

This 1/10 scale Tamiya R/C model perfectly replicates the distinctive silhouette with a robust polycarbonate body and utilizes many separately molded parts for maximum detail. It is based on the new MB-01 chassis, which allows for versatile drive configurations.

Highlights of the model

• Polycarbonate body of the Fiat Abarth 1000 TCR Berlina Corse
• Separately molded parts: side mirrors, hood, radiator area, rear details
• Open hood with realistic engine components
• Silver rims with differentiated tires (55 mm front, 59 mm rear)
• Compact dimensions ideal for indoor use and parking lots
• 540 motor included

MB-01 Chassis – Compact Versatility

The innovative MB-01 chassis allows for three wheelbases and a choice of front- or rear-wheel drive. This model is built in a mid-engine, rear-wheel-drive (MR) layout – ideal for agile, rear-biased handling.

• Three selectable wheelbases (this model: short 210 mm)
• Mid-engine behind the front axle, rear-wheel drive
• Quick switching between front- and rear-wheel drive without removing the RC components
• Symmetrical double wishbone suspension all around
• Friction damper as standard
• Flip-up battery holder for quick battery changes
• Compatible with TT-02 differentials (e.g., tuning options)
• Modular design for easy maintenance

Technical data

• Length: 374 mm
• Width: 168 mm
• Height: 140 mm
• Wheelbase: 210 mm
• Tire sizes: 25/55 mm front, 25/59 mm rear
• Chassis: MB-01 tub frame
• Drive: 2WD rear-wheel drive (MR)
• Differential: 4-Bevel (TT-02 type)
• Suspension: Double wishbone front & rear
• Damper: Friction
• Motor: 540 Brushed
• ESC: not included
• Translation: 5.83:1 (29T pinion)

Required accessories

• 2-channel remote control with receiver
• Electronic speed controller (ESC)
• Steering servo
• Driving battery 7.2–7.4 V (NiMH/LiPo)
• Charger
• AA batteries for the transmitter
