The Tamiya Landfreeder Quadtrack is a unique off-road model designed for extreme conditions. Instead of wheels, this vehicle uses four individually driven track modules , providing superior traction – whether on snow, mud, sand, or loose surfaces. Based on the proven TT-02 all-wheel-drive chassis, the Quadtrack offers impressive handling and a completely new level of off-road capability.

The body, in classic 1980s pickup truck style, is made of polycarbonate and enhanced with additional metallic trim such as a bull bar, auxiliary lights, and a roll bar. A special chassis cover with wheel arch covers reliably keeps out dirt and stones.

Highlights of the model

• 1/10 RC model kit without ESC
• Extremely off-road capable thanks to four individually suspended track modules
• Each chain has its own suspension, 8 rollers and drive via sprocket.
• Two chain types: Standard & Grouser (higher traction) – combinable
• Polycarbonate body in 80s pickup truck style
• Metal-plated attachments: front bar, fog lights, roll bar
• Chassis cover & wheel arch liner to protect against dirt
• Includes Tamiya CR-Tuned motor
• Perfect for winter, off-road, trail and fun rides

TT-02FT Chassis – TT-02 Technology with Chain Drive

• Based on the proven TT-02 4WD drivetrain
• Bathtub chassis with enclosed gearbox units
• Full-time all-wheel drive via driveshaft
• 4-bevel differentials front & rear
• 4-way double wishbone suspension
• Friction dampers front & rear
• High ground clearance for maximum off-road capability
• Translation: 8.27:1 (further pinions optional)

Technical data

• Length: 425 mm
• Width: 247 mm
• Height: 199 mm
• Wheelbase: 251 mm
• Chain width: 39 mm
• Chain contact area: approx. 60 mm per track
• Motor: Tamiya CR-Tuned
• ESC: not included

Required accessories

• 2-channel remote control including receiver
• Electronic speed controller (ESC)
• Steering servo (at least 8 kg recommended)
• Drive battery 7.2–7.4 V
• Suitable charger
• AA batteries for the transmitter
